The Ray Electric Outboard Motors are reliable, powerful, quiet outboard motor designed to give you and your family hassle free boating well into the twenty first century.

• Reliable – We’ve built motors since 1974, currently less than 1% of our motors are out of service.
• Powerful – Numerous tour boats throughout the world are powered by Ray motors. (one example: Homosassa Springs – up to 40 passengers per trip, used 8 hours a day)
• Quiet – Built with the finest gears and bearings available on the market today. Enjoy a conversation with family or friends while under way.

• The first motor to be designed and patented as a primary power electric outboard, not some type of adaptation of a trolling motor or gas outboard conversion

• One Year Warranty – 100% parts and labor

• The Ray Electric Outboard can be installed on just about any boat. There is no need to buy a factory electric boat that does not suit your lifestyle

• Delivers 195 lbs. of thrust (System 300)

• Over sized propeller - guaranteed not to bend or break

• Ease of installation and operation

• Built to withstand the daily rigors of heavy commercial use

• Non-polluting

• Starts instantly, every time

• Single lever control

• Economical – approximately $1.00 to charge overnight

• Boat steers easily in reverse, unlike boats equipped with an inboard motor

• No winterization required – except to keep the batteries charged

• Air cooled - no water pump to clog or burn out

• Smooth operation – doesn’t smoke, shake or make disturbing noise

• Easily fueled – just plug it in

• Single lever control (forward, reverse, variable speed) with efficient pulse modulated speed control

• Heavy duty General Electric motor

• Smooth direct reversing

• 12 ½ inch weedless prop

• 2.6 to 1 gear reduction

• Battery meter

• Patented dual pass air cooling

• Integral steering tube (link arm furnished)

• Twist grip control on tiller model

• Complete installation, maintenance, and operating instructions

Tiller Model

Options 48 volt (3.5 hp) or 36 volt (rated 2.2 hp) 25 ampere Battery Charger (36 or 48 volt), recharges completely discharged batteries is 12 hours, shuts off automatically Remote or tiller control Short (15 inch transom) or long shaft (24 inch transom) Saltwater package Slip clutch – prevents shear pin replacement Batteries – 75 amp, 135 min. rating, 65 lbs. (purchase locally, recommend Excide GCV 6-volt batteries) Plastic battery boxes (purchase locally)

Specifications

• Console, single lever control, measures 6 3/8" x 3 3/8" x 3 3/8" high
• Battery charger weighs 32 lbs., measures 12’’ x 9" x 12" high
• Batteries weigh 65 lbs. each, measure 10 ¼" x 7" x 11"

System No.	Rated HP	Volts	Number of Batteries	Outboard Weight	Total System Weight lbs.	Trolling Speed (Example)			Medium Speed (Example)			Top Speed (Example)
						HP	Running Time in Hrs.	Amps	HP	Running Time in Hrs.	Amps	HP	Running Time in Hrs.	Amps	Thrust pounds
						.
450 E-135	4.5	48	8	72	639	.33	38	6.5	1.7	6.0	32	4.5	1.9	85	240
450 E8V 110	4.5	48	6	72	497	.33	23	6.5	1.6	3.7	32	4.5	1.2	85	240
450 DC27 12V	4.5	48	4	72	322	.33	14	6.5	1.7	2.1	32	4.5	.6	85	240
240 E-135	2.4	36	6	72	503	.33	28	8.7	1.1	6.6	29	2.4	3.0	60	145
240 DC27 12V	2.4	36	3	72	267	.33	9.5	8.7	1.1	2.5	29	2.4	1.4	60	145



---

How far can you go in an electric boat?

Well-designed displacement boats powered by a Ray Electric Outboard has an extended cruising range of over 70 miles (@ over 6mph) on a single charge. However, the true facts are that most boaters (gas or electric powered) actually only cruise less than 25 miles a day.

How fast are electric boats?

Fast enough. The true facts are that those who are interested in electric boating enjoy a relaxed lifestyle such as cruising and conversing with friends, enjoying a meal on the water, fishing or sipping cocktails in the evening as the sun paints the sky.

Can’t I just use a trolling motor?

No. The true facts are that trolling motors are not designed as a primary source of power for a boat. They are designed as a secondary means of power. Using a trolling motor as a primary source of power, you will find that they are not very dependable and that they do not have sufficient power. So if you expect your boat to have the dependability and power to get you home when the wind kicks up, you had better have a Ray Electric Outboard on the back.

How reliable are electric outboards?

Very reliable if you choose a quality motor. The true facts are that Ray Electric Outboards began producing motors in 1974, and currently there are less than 1% of our motors out of service. In other words, we like to think it’s pretty reliable.

How can I be sure that I won’t run my batteries down?

Unlike flashlights, games and cordless drills, today’s electric boats are equipped with some type of meter. The true facts are electric boats can be equipped with the ultimate in 90’s technology. A Ray Electric Outboard comes equipped with a voltmeter; this meter shows you in an instant the state of charge of your batteries. In addition, we can provide an ammeter (indicates the amps being used) or an E meter (indicates the amount of run time by the amps being used) to further ensure your peace of mind while seeking new horizons.

Beck's Gunsmithing is certified Ray Sales & Warranty Service

Mike Beck shows off the quality built into a Ray Electric outboard Motor.
Years of experience with reservoir rigging and electronics make Beck's Gunsmithing your choice for purchasing your Ray or Minn Kota electric motors, Depth Finders, Excide Batteries.

Need help with rigging you boat for Liberty reservoir, Loch Raven Reservoir or Pretty Boy Reservoir?.....Mike Beck's consulting knowledge is worth it's weight in gold.
